Product images are for illustrative purposes only. The actual appearance of the item may differ slightly from the image shown, which does not affect its essential properties.
DK171004_NC-16RW56x63-XD16_VA01_P10M PCB-TECH - MCPCB dedicated to optics
Manufacturer code:
DK171004_NC-16RW56x63-XD16_VA01_P10M
MCPCB, thermal conductivity 2W/(m*K), thickness: 1.6mm, number of layers - 1, copper layer thickness 70um, white soldermask, legend color: colorless, size: rectangle 56x63mm, pad cover: llead-free tin; for KHATOD optics, /10
|
Quantity [pcs] |
Net price [PLN/pcs] |
|---|---|
| 1+ | 10.35 |
| 10+ | 9.84 |
| 50+ | 9.32 |
| 500+ | 8.28 |
Download files
Download files
Information
Manufacturer
PCB-TECH
Product code
MCPCB-KH-NC-16RW56X63-XD16_VA01
Manufacturer product code
DK171004_NC-16RW56x63-XD16_VA01_P10M
Customs number
8534001900
Technical data
Lenght mm
56
Number of LEDs
16
Thickness
1.6 mm
Laminate type
MCPCB
Shape
rectangle
Soldermask colour
white
Thermal conductivity
2W/(m*K)
Width mm
63
LED type
XD16
69
items in stock
Multiplicity: 1 pcs.
Minimum purchase quantity: 1 pcs.
Quantity
Total 10,35 PLN net
Contact consultant
Call or send a message, we’ll be happy to help
Lens for LED high power; angle: oval 150 x 110 degrees ; Number of LEDs: 4; Dimensions: 50x50mm; Height: 7.72mm; material: PMMA; Fastening: screw
Manufacturer code: KNAC0405ASM
Manufacturer: KHATOD
|
Quantity [pcs] |
Net price [/pcs] |
|---|---|
| 1+ | 2.82 |
| 10+ | 2.70 |
| 100+ | 2.26 |
| 1000+ | 1.98 |
47 250
pcs. estimated delivery date
Week 31 of 2026
27.07.2026 – 02.08.2026
Multiplicity: 1 pcs.
Minimum purchase quantity: 1 pcs.
Lens for LED high power; angle: oval 158 x 110 degrees ; Number of LEDs: 4; Dimensions: 50x50mm; Height: 7.21mm; material: PMMA; Fastening: screw
Manufacturer code: KNAC0406BSM
Manufacturer: KHATOD
|
Quantity [pcs] |
Net price [/pcs] |
|---|---|
| 1+ | 7.46 |
| 20+ | 7.09 |
| 100+ | 6.71 |
| 500+ | 5.97 |
40
items in stock
Multiplicity: 1 pcs.
Minimum purchase quantity: 1 pcs.
Quantity
Total 7,46 net
Lens for LED high power; angle: 50 degrees ; Number of LEDs: 4; Dimensions: 50x50mm; Height: 8.80mm; material: PMMA; Fastening: screw
Manufacturer code: KNAC0420ASM
Manufacturer: KHATOD
|
Quantity [pcs] |
Net price [/pcs] |
|---|---|
| 1+ | 7.46 |
| 10+ | 7.13 |
| 25+ | 6.71 |
| 100+ | 5.97 |
179
items in stock
Multiplicity: 1 pcs.
Minimum purchase quantity: 1 pcs.
Quantity
Total 7,46 net
Lens for LED high power; angle: oval 150 x 160 degrees ; Number of LEDs: 4; Dimensions: 50x50mm; Height: 7.43mm; material: PMMA; Fastening: screw
Manufacturer code: KNAC0424ASM
Manufacturer: KHATOD
|
Quantity [pcs] |
Net price [/pcs] |
|---|---|
| 1+ | 15.18 |
| 10+ | 14.50 |
| 25+ | 13.66 |
Lens for LED high power; angle: oval 150 x 80 degrees ; Number of LEDs: 4; Dimensions: 50x50mm; Height: 7.68mm; material: PMMA; Fastening: screw
Manufacturer code: KNAC0430ASM
Manufacturer: KHATOD
|
Quantity [pcs] |
Net price [/pcs] |
|---|---|
| 1+ | 12.52 |
| 10+ | 11.96 |
| 25+ | 11.27 |
Lens for LED high power; angle: oval 70 x 160 degrees ; Number of LEDs: 4; Dimensions: 50x50mm; Height: 8.99mm; material: PMMA; Fastening: screw
Manufacturer code: KNAC0435ASM
Manufacturer: KHATOD
|
Quantity [pcs] |
Net price [/pcs] |
|---|---|
| 1+ | 7.46 |
| 10+ | 7.13 |
| 25+ | 6.71 |
